Simplex 4100U Application Guide

5-13
Label: ACTIVATE SMOKE CONTROL ZONE 3 Equation 14
COMMENTS:
INPUTS:
The ON state of:
P278 UTILITY SMOKE CONTROL ZONE 3 INITIATE
DELAY for 5 sec., running timer is A286
OUTPUTS:
HOLD points OFF pri=8,9
M1-14 CDAMPER MAIN RETURN AIR DAMPER
M1-19 CDAMPER 1ST FLOOR EXHAUST/RETURN AIR DAMPER
M1-20 CDAMPER 2ND FLOOR EXHAUST/RETURN AIR DAMPER
M1-22 CDAMPER 4TH FLOOR EXHAUST/RETURN AIR DAMPER
M1-17 CDAMPER 3RD FLOOR SUPPLY AIR DAMPER
HOLD points ON pri=9,9
M1-11 CPRESS EXHAUST FAN RELAY
M1-13 CDAMPER MAIN EXHAUST AIR DAMPER
M1-17 CDAMPER 3RD FLOOR SUPPLY AIR DAMPER
M1-21 CDAMPER 3RD FLOOR EXHAUST/RETURN AIR DAMPER
M1-9 CPRESS STAIR PRESS FAN
END:
Label: INITIATE SMOKE ZONE 4 Equation 15
COMMENTS:
INPUTS:
The DETECT state of:
M1-4 FIRE 4TH FLOOR SMOKE
OUTPUTS:
HOLD points ON pri=8,8
P279 UTILITY SMOKE CONTROL ZONE 4 INITIATE
HOLD points OFF pri=7,7
P276 UTILITY SMOKE CONTROL ZONE 1 INITIATE
P277 UTILITY SMOKE CONTROL ZONE 2 INITIATE
P278 UTILITY SMOKE CONTROL ZONE 3 INITIATE
END:
Smoke Control System Custom Control Equations, Continued
Equation 14:
Activate Smoke
Control Zone 3
Equation 15:
Initiate Smoke
Zone 4

Simplex 4100U Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Max Signaling Line Circuits (SLC)	2
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	10% to 93% non-condensing
Network Capability	Yes
Communication Protocol	RS-232, RS-485
Battery Backup	24 VDC
NAC Outputs	4
Signaling Line Circuits (SLCs)	2
Power Supply Current	3.0 A
Max Notification Appliance Circuits (NAC)	4
Max Releasing Circuits	4
Max Relay Circuits	4
Communication Ports	RS-232, RS-485
