Simplex 4100U Application Guide

5-20
Label: REPORT TBL IF EXH DAMPER 1 NOT OPEN Equation 39
COMMENTS:
INPUTS:
The ON state of:
M1-19 CDAMPER 1ST FLOOR EXHAUST/RETURN AIR DAMPER
DELAY for 10 sec., running timer is A258
AND NOT the ON state of:
M1-33 UTILITY MONITOR FLR 1 EXHAUST AIR DAMPER OPEN
OUTPUTS:
HOLD points ON pri=9,9
P264 UTILITY FL1 EXHAUST AIR DAMPER FAIL
END:
Label: REPORT TBL IF EXH DAMPER 1 NOT CLOSED Equation 40
COMMENTS:
INPUTS:
NOT the ON state of:
M1-19 CDAMPER 1ST FLOOR EXHAUST/RETURN AIR DAMPER
DELAY for 10 sec., running timer is A276
AND NOT the ON state of:
M1-37 UTILITY MONITOR FLR 1 EXHAUST AIR DAMPER CLOSED
OUTPUTS:
HOLD points ON pri=9,9
P264 UTILITY FL1 EXHAUST AIR DAMPER FAIL
END:
Label: REPORT TBL IF EXH DAMPER 2 NOT OPEN Equation 41
COMMENTS:
INPUTS:
The ON state of:
M1-20 CDAMPER 2ND FLOOR EXHAUST/RETURN AIR DAMPER
DELAY for 10 sec., running timer is A277
AND NOT the ON state of:
M1-34 UTILITY MONITOR FLR 2 EXHAUST AIR DAMPER OPEN
OUTPUTS:
HOLD points ON pri=9,9
P265 UTILITY FL2 EXHAUST AIR DAMPER FAIL
END:
Label: REPORT TBL IF EXH DAMPER 2 NOT CLOSED Equation 42
COMMENTS:
INPUTS:
NOT the ON state of:
M1-20 CDAMPER 2ND FLOOR EXHAUST/RETURN AIR DAMPER
DELAY for 10 sec., running timer is A259
AND NOT the ON state of:
M1-38 UTILITY MONITOR FLR 2 EXHAUST AIR DAMPER CLOSED
OUTPUTS:
HOLD points ON pri=9,9
P265 UTILITY FL2 EXHAUST AIR DAMPER FAIL
END:
Smoke Control System Custom Control Equations, Continued
Equation 39:
Report TBL if EXH
Damper 1 Not Open
Equation 40:
Report TBL If EXH
Damper 1 Not
Closed
Equation 41:
Report TBL If EXH
Damper 2 Not Open
Equation 42:
Report TBL If
EXH Damper 2
Not Closed

Simplex 4100U Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Max Signaling Line Circuits (SLC)	2
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	10% to 93% non-condensing
Network Capability	Yes
Communication Protocol	RS-232, RS-485
Battery Backup	24 VDC
NAC Outputs	4
Signaling Line Circuits (SLCs)	2
Power Supply Current	3.0 A
Max Notification Appliance Circuits (NAC)	4
Max Releasing Circuits	4
Max Relay Circuits	4
Communication Ports	RS-232, RS-485
