Simplex 4100U Application Guide

5-17
Label: REPORT TBL IF MAIN SUP DAMPER NOT OPEN Equation 27
COMMENTS:
INPUTS:
The ON state of:
M1-12 CDAMPER MAIN OUTSIDE AIR DAMPER
DELAY for 10 sec., running timer is A266
AND NOT the ON state of:
M1-48 UTILITY MONITOR OUTSIDE AIR DAMPER OPEN
OUTPUTS:
HOLD points ON pri=9,9
P271 UTILITY MAIN SUPPLY AIR DAMPER FAIL
END:
Label: REPORT TBL IF MAIN SUP DAMPER NOT CLOSED Equation 28
COMMENTS:
INPUTS:
NOT the ON state of:
M1-12 CDAMPER MAIN OUTSIDE AIR DAMPER
DELAY for 10 sec., running timer is A267
AND NOT the ON state of:
M1-49 UTILITY MONITOR OUTSIDE AIR DAMPER CLOSED
OUTPUTS:
HOLD points ON pri=9,9
P271 UTILITY MAIN SUPPLY AIR DAMPER FAIL
END:
Label: REPORT TBL IF MAIN RET DAMPER NOT OPEN Equation 29
COMMENTS:
INPUTS:
The ON state of:
M1-14 CDAMPER MAIN RETURN AIR DAMPER
DELAY for 10 sec., running timer is A268
AND NOT the ON state of:
M1-45 UTILITY MONITOR MAIN RETURN AIR DAMPER OPEN
OUTPUTS:
HOLD points ON pri=9,9
P270 UTILITY MAIN RETURN AIR DAMPER FAIL
END:
Label: REPORT TBL IF MAIN RET DAMPER NOT CLOSED Equation 30
COMMENTS:
INPUTS:
NOT the ON state of:
M1-14 CDAMPER MAIN RETURN AIR DAMPER
DELAY for 10 sec., running timer is A269
AND NOT the ON state of:
M1-46 UTILITY MONITOR MAIN RETURN AIR DAMPER CLOSED
OUTPUTS:
HOLD points ON pri=9,9
P270 UTILITY MAIN RETURN AIR DAMPER FAIL
END:
Smoke Control System Custom Control Equations, Continued
Equation 27:
Report TBL if
Main SUP Damper
Not Open
Equation 28:
Report TBL if Main
SUP Damper Not
Closed
Equation 29:
Report TBL if
Main RET Damper
Not Open
Equation 30:
Report TBL if Main
RET Damper Not
Closed

Simplex 4100U Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Max Signaling Line Circuits (SLC)	2
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	10% to 93% non-condensing
Network Capability	Yes
Communication Protocol	RS-232, RS-485
Battery Backup	24 VDC
NAC Outputs	4
Signaling Line Circuits (SLCs)	2
Power Supply Current	3.0 A
Max Notification Appliance Circuits (NAC)	4
Max Releasing Circuits	4
Max Relay Circuits	4
Communication Ports	RS-232, RS-485
