5-5
The following Custom Control (CC) equations are written for a 4100U/4100ES based smoke
control system. Note that the points mentioned are representative of any system. Your system will
use different points to provide the Inputs and Outputs.
The following “Custom Control Equation Summary” gives the CC equation number followed by a
label (title) for the program.
CUSTOM CONTROL EQUATION SUMMARY
Equation No. Label
------------------- ----------------------------------------
1 SET UP NORMAL CONDITIONS AT STARTUP
2 CLEAR FAULTS ON STARTUP
3 SET NORMAL CONDITIONS AT RESET
4 REPORT TROUBLE IF SWITCHES NOT RESET
5 INITIALIZE NORMAL CONDITIONS AT RESET
6 NORMAL CONDITIONS COMPLETE AFTER RESET
7 SMOKE CONTROL INITIATE
8 SMOKE CONTROL RESET
9 INITIATE SMOKE ZONE 1
10 ACTIVATE SMOKE CONTROL ZONE 1
11 INITIATE SMOKE ZONE 2
12 ACTIVATE SMOKE CONTROL ZONE 2
13 INITIATE SMOKE ZONE 3
14 ACTIVATE SMOKE CONTROL ZONE 3
15 INITIATE SMOKE ZONE 4
16 ACTIVATE SMOKE CONTROL ZONE 4
17 SUPPLY FAN DUCT SMOKE ALARM
18 STAIR PRESS FAN DUCT SMOKE ALARM
19 REPORT TBL IF SUPPLY FAN NOT ON
20 REPORT TBL IF SUPPLY FAN NOT OFF
21 REPORT TBL IF EXHAUST FAN NOT ON
22 REPORT TBL IF EXHAUST FAN NOT OFF
23 REPORT TBL IF STAIR PRESS FAN NOT ON
24 REPORT TBL IF STAIR PRESS FAN NOT OFF
25 REPORT TBL IF MAIN EXH DAMPER NOT OPEN
26 REPORT TBL IF MAIN EXH DAMPER NOT CLOSED
27 REPORT TBL IF MAIN SUP DAMPER NOT OPEN
28 REPORT TBL IF MAIN SUP DAMPER NOT CLOSED
29 REPORT TBL IF MAIN RET DAMPER NOT OPEN
30 REPORT TBL IF MAIN RET DAMPER NOT CLOSED
31 REPORT TBL IF SUP DAMPER 1 NOT OPEN
32 REPORT TBL IF SUP DAMPER 1 NOT CLOSED
33 REPORT TBL IF SUP DAMPER 2 NOT OPEN
34 REPORT TBL IF SUP DAMPER 2 NOT CLOSED
35 REPORT TBL IF SUP DAMPER 3 NOT OPEN
36 REPORT TBL IF SUP DAMPER 3 NOT CLOSED
37 REPORT TBL IF SUP DAMPER 4 NOT OPEN
38 REPORT TBL IF SUP DAMPER 4 NOT CLOSED
39 REPORT TBL IF EXH DAMPER 1 NOT OPEN
40 REPORT TBL IF EXH DAMPER 1 NOT CLOSED
41 REPORT TBL IF EXH DAMPER 2 NOT OPEN
42 REPORT TBL IF EXH DAMPER 2 NOT CLOSED
43 REPORT TBL IF EXH DAMPER 3 NOT OPEN
Continued on next page
Smoke Control System Custom Control Equations
Introduction
Smoke Control
System CC Equation
Summary
