Simplex 4100U Application Guide

5-6
Equation No. Label
------------------- -------------------------------------------------------------------
44 REPORT TBL IF EXH DAMPER 3 NOT CLOSED
45 REPORT TBL IF EXH DAMPER 4 NOT OPEN
46 REPORT TBL IF EXH DAMPER 4 NOT CLOSED
47 MANUAL CONTROL SUP AIR DAMPER 1 OPEN
48 MANUAL CONTROL SUP AIR DAMPER 1 CLOSE
49 MANUAL CONTROL SUP AIR DAMPER 2 OPEN
50 MANUAL CONTROL SUP AIR DAMPER 2 CLOSE
51 MANUAL CONTROL SUP AIR DAMPER 3 OPEN
52 MANUAL CONTROL SUP AIR DAMPER 3 CLOSE
53 MANUAL CONTROL SUP AIR DAMPER 4 OPEN
54 MANUAL CONTROL SUP AIR DAMPER 4 CLOSE
55 MANUAL CONTROL EXH AIR DAMPER 1 OPEN
56 MANUAL CONTROL EXH AIR DAMPER 1 CLOSE
57 MANUAL CONTROL EXH AIR DAMPER 2 OPEN
58 MANUAL CONTROL EXH AIR DAMPER 2 CLOSE
59 MANUAL CONTROL EXH AIR DAMPER 3 OPEN
60 MANUAL CONTROL EXH AIR DAMPER 3 CLOSE
61 MANUAL CONTROL EXH AIR DAMPER 4 OPEN
62 MANUAL CONTROL EXH AIR DAMPER 4 CLOSE
63 MANUAL CONTROL STAIR PRESS FAN ON
64 MANUAL CONTROL STAIR PRESS FAN OFF
65 MANUAL CONTROL MAIN SUPPLY FAN ON
66 MANUAL CONTROL MAIN SUPPLY FAN OFF
67 MANUAL CONTROL MAIN RET AIR DAMPER OPEN
68 MANUAL CONTROL MAIN RET AIR DAMPER CLOSE
69 MANUAL CONTROL MAIN EXHAUST FAN ON
70 MANUAL CONTROL MAIN EXHAUST FAN OFF
71 MANUAL CONTROL MAIN SUP AIR DAMPER OPEN
72 MANUAL CONTROL MAIN SUP AIR DAMPER CLOSE
73 MANUAL CONTROL MAIN EXH AIR DAMPER OPEN
74 MANUAL CONTROL MAIN EXH AIR DAMPER CLOSE
75 MANUAL CONTROL CLEAR FAULTS
76 MASTER KEY SWITCH
77 TURN SONALERT ON
78 TURN SONALERT OFF
[END-OF-PROGRAM]
Smoke Control System Custom Control Equations, Continued
Smoke Control
System CC Equation
Summary

Simplex 4100U Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Max Signaling Line Circuits (SLC)	2
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	10% to 93% non-condensing
Network Capability	Yes
Communication Protocol	RS-232, RS-485
Battery Backup	24 VDC
NAC Outputs	4
Signaling Line Circuits (SLCs)	2
Power Supply Current	3.0 A
Max Notification Appliance Circuits (NAC)	4
Max Releasing Circuits	4
Max Relay Circuits	4
Communication Ports	RS-232, RS-485
