Simplex 4100U Application Guide

5-4
Label: TEST STAIRWELL AIR PRESSURE Equation 3
COMMENTS:
INPUTS:
The ON state of:
P281 UTILITY START SELF TEST PROGRAM
AND the ON state of:
M1-9 CPRESS STAIR PRESS FAN
DELAY for 10 secs, running timer is A283
AND NOT the ON state of:
M1-42 UTILITY MONITOR STAIR PRESS FAN ON
OUTPUTS:
HOLD points ON pri=9,9
P280 UTILITY STAIR PRESS FAN FAIL
END:
Label: RESET STAIR PRESSURE FAN TO OFF Equation 4
COMMENTS:
INPUTS:
The ON state of:
P281 UTILITY START SELF TEST PROGRAM
AND the ON state of:
M1-9 CPRESS STAIR PRESS FAN
DELAY for 60 secs, running timer is A284
OUTPUTS:
HOLD points OFF pri=9,9
M1-9 CPRESS STAIR PRESS FAN
P281 UTILITY START SELF TEST PROGRAM
PRINT to All ports/logs/displays
"SELF TEST PROGRAM IS COMPLETE"
END:
Label: [END-OF-PROGRAM] Equation 5
Dedicated Smoke Control System Weekly Self-Test, Continued
Equation 3:
Test Stairwell
Air Pressure
Equation 4:
Reset Stair Pressure
Fan to OFF
Equation 5:
End of Program

Simplex 4100U Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Max Signaling Line Circuits (SLC)	2
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	10% to 93% non-condensing
Network Capability	Yes
Communication Protocol	RS-232, RS-485
Battery Backup	24 VDC
NAC Outputs	4
Signaling Line Circuits (SLCs)	2
Power Supply Current	3.0 A
Max Notification Appliance Circuits (NAC)	4
Max Releasing Circuits	4
Max Relay Circuits	4
Communication Ports	RS-232, RS-485
