5-16
Label: REPORT TBL IF STAIR PRESS FAN NOT ON Equation 23
COMMENTS:
INPUTS:
The ON state of:
M1-9 CPRESS STAIR PRESS FAN
DELAY for 10 sec., running timer is A265
AND NOT the ON state of:
M1-42 UTILITY MONITOR STAIR PRESS FAN ON
OUTPUTS:
HOLD points ON pri=9,9
P280 UTILITY STAIR PRESS FAN FAIL
END:
Label: REPORT TBL IF STAIR PRESS FAN NOT OFF Equation 24
COMMENTS:
INPUTS:
NOT the ON state of:
M1-9 CPRESS STAIR PRESS FAN
DELAY for 10 sec., running timer is A290
AND NOT the ON state of:
M1-47 UTILITY MONITOR STAIR PRESS FAN OFF
OUTPUTS:
HOLD points ON pri=9,9
P280 UTILITY STAIR PRESS FAN FAIL
END:
Label: REPORT TBL IF MAIN EXH DAMPER NOT OPEN Equation 25
COMMENTS:
INPUTS:
The ON state of:
M1-13 CDAMPER MAIN EXHAUST AIR DAMPER
DELAY for 10 sec., running timer is A262
AND NOT the ON state of:
M1-51 UTILITY MONITOR MAIN EXHAUST AIR DAMPER OPEN
OUTPUTS:
HOLD points ON pri=9,9
P272 UTILITY MAIN EXHAUST AIR DAMPER FAIL
END:
Label: REPORT TBL IF MAIN EXH DAMPER NOT CLOSED Equation 26
COMMENTS:
INPUTS:
NOT the ON state of:
M1-13 CDAMPER MAIN EXHAUST AIR DAMPER
DELAY for 10 sec., running timer is A281
AND NOT the ON state of:
M1-52 UTILITY MONITOR MAIN EXHAUST AIR DAMPER CLOSED
OUTPUTS:
HOLD points ON pri=9,9
P272 UTILITY MAIN EXHAUST AIR DAMPER FAIL
END:
Smoke Control System Custom Control Equations, Continued
Equation 23:
Report TBL if Stair
Press Fan Not ON
Equation 24:
Report TBL if Stair
Press Fan Not OFF
Equation 25:
Report TBL if
Main EXH Damper
Not Open
Equation 26:
Report TBL if
Main EXH Damper
Not Closed
