Label: MANUAL CONTROL EXH AIR DAMPER 3 OPEN Equation 59
COMMENTS:
INPUTS:
The UP state of:
8-71 SWITCH Ann 1 Pt 71 Graphic LED/SW Ctlr w/32
AND the ON state of:
P273 UTILITY MASTER KEY SWITCH ENABLE
OUTPUTS:
HOLD points ON pri=5,9
M1-21 CDAMPER 3RD FLOOR EXHAUST/RETURN AIR DAMPER
END:
Label: MANUAL CONTROL EXH AIR DAMPER 3 CLOSE Equation 60
COMMENTS:
INPUTS:
The DOWN state of:
8-71 SWITCH Ann 1 Pt 71 Graphic LED/SW Ctlr w/32
AND the ON state of:
P273 UTILITY MASTER KEY SWITCH ENABLE
OUTPUTS:
HOLD points OFF pri=5,9
M1-21 CDAMPER 3RD FLOOR EXHAUST/RETURN AIR DAMPER
END:
Label: MANUAL CONTROL EXH AIR DAMPER 4 OPEN Equation 61
COMMENTS:
INPUTS:
The UP state of:
8-73 SWITCH Ann 1 Pt 73 Graphic LED/SW Ctlr w/32
AND the ON state of:
P273 UTILITY MASTER KEY SWITCH ENABLE
OUTPUTS:
HOLD points ON pri=5,9
M1-22 CDAMPER 4TH FLOOR EXHAUST/RETURN AIR DAMPER
END:
Label: MANUAL CONTROL EXH AIR DAMPER 4 CLOSE Equation 62
COMMENTS:
INPUTS:
The DOWN state of:
8-73 SWITCH Ann 1 Pt 73 Graphic LED/SW Ctlr w/32
AND the ON state of:
P273 UTILITY MASTER KEY SWITCH ENABLE
OUTPUTS:
HOLD points OFF pri=5,9
M1-22 CDAMPER 4TH FLOOR EXHAUST/RETURN AIR DAMPER
END:
Smoke Control System Custom Control Equations, Continued
Equation 59:
Control EXH Air
Damper 3 Open
Equation 60:
Manual Control EXH
Air Damper 3 Close
Equation 61:
Manual Control EXH
Air Damper 4 Open
Equation 62:
Manual Control EXH
Air Damper 4 Close

Simplex 4100U Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Max Signaling Line Circuits (SLC)	2
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	10% to 93% non-condensing
Network Capability	Yes
Communication Protocol	RS-232, RS-485
Battery Backup	24 VDC
NAC Outputs	4
Signaling Line Circuits (SLCs)	2
Power Supply Current	3.0 A
Max Notification Appliance Circuits (NAC)	4
Max Releasing Circuits	4
Max Relay Circuits	4
Communication Ports	RS-232, RS-485
