2-8
Position the monitor close enough to the PC so that you can connect the cables
from the monitor to the PC and perform the following steps:
1. Connect the touchscreen controller cable to the touchscreen controller
connector on the back of the PC.
2. Connect the other end of the cable to the touchscreen input connector on the
back of the touchscreen monitor.
Caution: Make sure there is a
1
/16 inch space between the
touchscreen bezel and the screen. (The bezel and the
screen should not touch.)
Connect the mouse by completing the following steps:
1. Locate the mouse connector on the back of the PC.
2. Plug the connector on the end of the mouse cable into the mouse connector
on the back of the PC.
Connect the keyboard by completing the following steps:
1. Locate the keyboard connector on the back of the PC.
2. Plug the connector on the end of the keyboard cable into the keyboard
connector on the back of the PC.
Connect the software key by completing the following steps:
1. Locate the LPT1 connector on the back of the PC.
2. Plug the software key into the LPT1 connector.
3. If desired, plug the printer cable into the software key.
Connect the printer by performing the following steps:
1. Locate the LPT1 connector on the back of the PC (it should already have a
software key connected to it).
2. Plug the printer cable into the software key which is plugged into the LPT1
connector.
3. Plug the other end of the printer cable into the printer.
Continued on next page
Connecting the GCC to the System, Continued
Connecting a Touchscreen
Monitor
Connecting The Mouse
Connecting The Keyboard
Connecting The Software Key
Connecting The Printer
(Optional)
To Next Page
