Simplex 4190 Graphical - Installing Touchscreen Software (Windows 3.1); Table 3-3. ELO Touch Systems, (Version 2.0 C) Installation Settings

3-7
This section describes the installation of the Touchscreen software (driver) for
Windows 3.1.
1. Insert the Elodev Touchscreen Controller Software Version 2.0 in the floppy
disk drive (typically, drive A). Exit Windows to DOS.
Note: The Touchscreen Drivers cannot be installed while Windows is
running.
2. Type A:install at the DOS prompt. The system begins the installation.
3. Follow the prompts on the screen, and select the options listed in Table 3-3.
Table 3-3. ELO Touch Systems, (Version 2.0C) Installation Settings
Field Setting/Action
DOS and Windows Driver Press Enter
Updating? Press Enter
Installation steps Press Enter
Installation Paths Press Enter
Touchscreen Driver Windows 3.1 Express
Installation
Differ Files Select No
Touchscreen Controller
Interface
Select PC bus (GCC)
-or- Select Serial (NPU)
Touchscreen Controller Model Select E271-2201 (GCC)
-or- Select E271-2210 (NPU)
Controller Base I/O Port Select 280 (default)
Controller Interrupt Select IRQ 2
Testing for Controller Verify that the E271-2201 (GCC)
or E271-2210 (NPU) Controller
was detected and that the
controller power-on self tests
have passed. If there is a
problem, this screen will indicate
that the controller was not found
or that the self test failed.
Enter the directory for your
local Microsoft Windows files
Select C:\WINDOWS
Updating Batch File Press Enter
Saving C:\AUTOEXEC.BAT to
C:\AUTOEXEC.OLD
Overwrite Back-up file
Update SYSTEM.INI Press Enter
Installing the Software, Continued
Installing Touchscreen
Software (Windows 3.1)
