Simplex 4190 Graphical - Figure 4-1. Rack-Mount Installation

4-3
Figure 4-1. Rack-Mount Installation
Installing the Rack-Mount Components, Continued
Installation Procedure
(Continued)
Tie Wrap
(Supplied in Ship Group)
Tie Wrap
Rear View
PC
Front
Surge
Protector
AC Termination
Rear
Label
Bottom Plate
17-Inch or 19-Inch
Monitor
Keyboard in
Rack Frame
Rack
(Shipped Assembled except
For PC and Monitor)
