Simplex 4190 Graphical - Switch Settings; UL Card (P;N 565-283); Table 6-7. UL Card  Host Address I;O Selection Via SW1; Table 6-8. UL Card  Serial Ports a & B (COM3 & COM4)

6-6
This section explains how to configure the UL Card (Model 4190-8103 GCC
only). Ensure that the switches are set on the UL card as listed in Tables 6-7 and
6-8.
Table 6-7. UL Card  Host Address I/O Selection Via SW1
Switch State
SW1-1 OFF
SW1-2 OFF
SW1-3 OFF
SW1-4 OFF
Table 6-8. UL Card  Serial Ports A & B (COM3 & COM4)
Configuration Via SW2
Switch No COM Ports
(No Daughter
Cards (Default)
COM3 Only
(Port A)
(1 Daughter
Card)
COM3 & COM4
(Port B)
(2 Daughter
Cards)
SW2-1 OFF OFF OFF
SW2-2 OFF ON ON
SW2-3 OFF ON ON
SW2-4 OFF ON ON
SW2-5 OFF OFF ON
SW2-6 OFF OFF ON
SW2-7 OFF OFF OFF
SW2-8 OFF OFF OFF
Switch Settings
UL Card (P/N 565-283)
