2-9
Connect the Uninterruptible Power Supply (UPS) by completing the following
steps:
1. Plug the PC, printer, and monitor power cords into the AC outlet which is
integral to the equipment rack.
2. Connect the dedicated branch circuit to the AC power input of the UPS.
3. Connect the output of the UPS (in conduit) to the AC input terminals
provided on the equipment rack.
4. Connect the transfer contacts of the UPS to the first of the general purpose
I/O points on the UL I/O card (see diagram 841-947 for interconnection
specifics).
Note: A UPS is required for fire-protective signaling applications.
The UPS itself must be UL 1481-listed for fire protective
signaling use.
Complete the following steps for each network interface card you are installing.
You can install up to four network interface cards in a GCC.
1. Locate the network interface card on the back of the PC.
2. Connect the cable from the previous node’s left port to the top connector on
the network card.
3. Connect the next node’s right port to the bottom connector on the network
card.
Connecting the GCC to the System, Continued
Connecting the Optional
Uninterruptible Power Supply
(UPS)
Connecting to a Network
To Next Page
