Simplex 4190 Graphical - Configuring the Serial Ports; Table 6-9. Port Selection Settings

6-8
To configure the serial ports listed in Table 6-9, complete the following steps:
1. From the 4190 Programmer Screen, select the File Hardware Config menu
options. The system displays the Hardware Configuration screen.
2. Use the selections in Table 6-9 to configure the port fields displayed on the
screen.
Table 6-9. Port Selection Settings
Ports Selection
No ports used NONE
Port A Select RS-232 for port A and NONE for Port B
Ports A & B Select RS-232 for both ports
Configuring the Ports, Continued
Configuring the Serial Ports
