6-11
Ensure that the Touchscreen Controller Card jumpers (P/N 2201 printed on card)
are set as listed in Table 6-14.
Table 6-14. Touchscreen Controller Card Jumper Positions
Jumper Position
J0 N
J1 N
J2 N
J3 N
J4 N
J5 N - Duratouch
Y - Accutouch
J6 N
J7 Y
J8 N
J9 N
J10 N
This section explains how to insert cards and connect the cables to the GCC
Desktop Models 4190-8102 and 4190-8103. Table 6-15 lists the correct slot
positions in the GCC backplane
Table 6-15. GCC Desktop Models Card Slot Positions
Card Slot #
Controller Card Slot #1 (Leftmost)
Network Card Install the first Network card in
Slot #3 and (if applicable), each
additional Network card (up to 3)
in slots 4 through 6.
Continued on next page
Installing Cards and Jumpers
Touchscreen Controller Card
Inserting and Connecting
Cards in the GCC
