Simplex 4190 Graphical - Jumper Settings; Wired Media Card (P;N 565-413); Fiber Optic Media Assembly; Table 6-5. RS-232 Media Card  Jumper Positions

6-5
Table 6-5 lists the jumper configurations for all RS-232 media cards.
Table 6-5. RS-232 Media Card  Jumper Positions
Jumper Function Position
P3 Network and UL Media Mother
Board
1-2 (default)
Service Port 2-3
P4 UL Board and Media Mother
Board
1-2 (default)
Network and Service Port 2-3
P5 Supervised 1-2 (default)
Unsupervised 2-3
Table 6-6 lists the jumper configurations for all wired media cards.
Table 6-6. Wired Media Card  Jumper Positions
Jumper Function Position
1 & 2
P2 18 AWG Cable 3 & 4
5 & 6
7 & 8
24 AWG Cable 3 & 4
There are no jumpers on the fiber optic media assembly.
Jumper Settings
RS-232 Media Card
(P/N 565-327)
Wired Media Card
(P/N 565-413)
Fiber Optic Media Assembly
