Simrad GC80 User Manual

DIP SWITCH SETTINGS
20221537 / D 113
JUMPER DEFAULT FUNCTION DESCRIPTION
J29 1-2 short
Setting of polarity for
"external heading
sensor" signal
Input port: GTERM board,
TB1 " ESRX"
1-2 short = Standard
3-4 short = Polarity is carried out
reversely.
NOTE:
When a signal cannot
be received by "1-2
short", it is set as "3-4
short."
NOTE
: Never use both
jumpers at the same
time!
J30 Short
Software install or
internal communication
with SCOIF board
Short = Internal
communication with
External heading
sensor
Open = Software is installed
in SCOIF board
NOTE:
A damage will be
given to a circuit if
software is installed
while this jumper has
been short.
J31 Short Software installation
Open = Software is installed
in SCOIF board
NOTE:
A damage will be
given to a circuit if
software is installed
while this jumper has
been short.
J32 Open CPU reset
This jumper is used when
resetting "CPU."

Simrad GC80 Specifications

General

Type	Gyro Compass
Power Supply	24 V DC
Operating Temperature	-15°C to +55°C
Heading Resolution	0.01°
Heading Repeatability	±0.1°
IP Rating	IP66
Storage Temperature	+70°C
Interfaces	NMEA 0183
Humidity	95% non-condensing
