Simrad GC80 User Manual

Simrad GC80/GC85 Dual Gyro Compass
114 20221537 / D
JUMPER DEFAULT FUNCTION DESCRIPTION
J33 1-2 short
1-2 short = Standard (The serial
signal of a standard
external direction
sensor is received,
and the signal is
sent to "NO.1 Gyro
compass")
3-4 short = With an external
heading sensor (with
HDM or EHS unit)
Type M or E.
J34 1-2 short
1-2 short = Standard (The serial
signal of a standard
external direction
sensor is received,
and the signal is
sent to "NO.2 Gyro
compass")
3-4 short = With an external
heading sensor (with
HDM or EHS unit)
Type M or E.
J35 1-2 short
1-2 short = Standard (The serial
signal of a standard
external direction
sensor is received,
and the signal is
receive from
"external heading
sensor")
3-4 short = With an external
heading sensor (with
HDM or EHS unit)
Type M or E.
J36 1-2 short
Selection of Output
serial signal
1-2 short = Standard (The serial
signal of a standard
external direction
sensor is received,
and the signal is
receive from
"external heading
sensor")
3-4 short = With an external
heading sensor (with
HDM or EHS unit)
Type M or E.

Simrad GC80 Specifications

General

Type	Gyro Compass
Power Supply	24 V DC
Operating Temperature	-15°C to +55°C
Heading Resolution	0.01°
Heading Repeatability	±0.1°
IP Rating	IP66
Storage Temperature	+70°C
Interfaces	NMEA 0183
Humidity	95% non-condensing
