Simrad GC80 User Manual

DIP SWITCH SETTINGS
20221537 / D 115
JUMPER DEFAULT FUNCTION DESCRIPTION
J37 3-4 short
Output port：GTERM board, TB2:
"6TX"
1-2 short = EC61162-2 or
TOKIMEC version
3-4 short = IEC61162-1 ed.2
(ref. page 4)
NOTE:
Never use both jumpers
at the same time!
J38 3-4 short
Output port：GTERM board, TB2:
"7TX"
1-2 short = IEC61162-2 or
TOKIMEC version
3-4 short = IEC61162-1 ed.2
(ref. page 4)
NOTE:
Never use both jumpers
at the same time!
J39 3-4 short
Output port：GTERM board, TB2:
"8TX"
1-2 short = IEC61162-2 or
TOKIMEC version
3-4 short = IEC61162-1 ed.2
(ref. page 4)
NOTE:
Never use both jumpers
at the same time!
J40 3-4 short
Output port：GTERM board, TB1:
"9TX"
1-2 short = IEC61162-2 or
TOKIMEC version
3-4 short = IEC61162-1 ed.2
(ref. page 4)
NOTE:
Never use both jumpers
at the same time!
J41 3-4 short
Output serial signal
Output port: GTERM board, TB1:
"10TX"
1-2 short = IEC61162-2 or
TOKIMEC version
3-4 short = IEC61162-1 ed.2
(ref. page 4)
NOTE:
Never use both jumpers
at the same time!

Simrad GC80 Specifications

General

Type	Gyro Compass
Power Supply	24 V DC
Operating Temperature	-15°C to +55°C
Heading Resolution	0.01°
Heading Repeatability	±0.1°
IP Rating	IP66
Storage Temperature	+70°C
Interfaces	NMEA 0183
Humidity	95% non-condensing
