AIS information on radar panels
The radar data bar includes information about targets.
The targets are listed with the closest target on top, and are color
coded to indicate target status.
Calling an AIS vessel
If the system includes a VHF radio supporting DSC (Digital Select
Calling) calls over NMEA 2000, a DSC call can be initiated to other
vessels from the unit.
The call option is available in the AIS vessel details dialog, and in the
vessel status dialog. Refer to "Displaying target information" on page 136.
DSC Vessel tracking
DSC (Digital Selective Calling) is a semi-automated method of
requesting or receiving position data from a vessel with a DSC VHF
radio. For more information on how to use this, refer to your VHF
radio manual.
There are various types of DSC position messages, including distress
calls. The type of message made determines information sent with
the call, and how the radio and MFD respond to the incoming call.
When a DSC message has been received, the MFD will
display a DSC vessel icon on the chart panel and radar
panel at the received coordinates. In addition, some radios
will send COG and SOG with the position data. This allows
for correct orientation of the icon.
When receiving a distress message you will see an alarm box
informing you that a message has been received. This can be read
under the messages tab on the vessels dialog. Select the vessels
button in the toolbar to display the vessels dialog.
138
AIS | GO XSE/XSR Operator Manual
