Simrad GO XSE Series User Manual

Icon Description
Pan to position a chart or sonar image on the
panel.
Pinch to zoom out on the chart or on an image.
Ú
Note: Not available for zooming sonar images.
Spread to zoom in on the chart or on an image.
Ú
Note: Not available for zooming sonar images.
Status bar icon definitions
Depending on your system and set up, the following icons can
appear on the status bar:
Icon Definition
Alarm - a standard (yellow), important (orange) or
critical (red) alarm is sent. To remove the icon in the
status bar, acknowledge the alarm in the Alarms
dialog. If needed, change the alarm setting or
remedy the situation so the same alarm is not resent
immediately by the system.
Autopilot modes: Auto-Heading hold, Follow up,
Navigation, No drift, Standby. Use the autopilot
controller to select an autopilot mode.
Appendix | GO XSE/XSR Operator Manual
237
