14. Spare parts
EN
14. Spare parts
Figure 9. Spare parts
14. Spare parts
The spare part assemblies specified herein
should only be used for replacing identical
defective assemblies. Using spare parts to
modify existing products is not allowed.
Table 7. Spare parts
Item Description Order code
1 Low level switch 10543528
2 Solenoid valve 11601420
3 Pneumatic actuator 11770250
4 M12 branch cable 11500194
5 Filling connector 11770460
6 Filling filter 11770415
7 Pressure switch 11601477
8 Discharge valve 11390730
9 Overfill relief valve 11770490
10
Visual Level indicator –
4 l reservoir
11771545
11
Visual Level indicator –
10 l reservoir
11771548
7 5,6
5,6
1
1
4
4
3
3
7
2
2
8
8
9
9
11
7
5,6
5,6
1
4
4
3
3
7
2
2
8
8
9
9
10
