CONTROLS, INSTRUMENTS AND E QUIPMENT
There are mainly three positions to
choose from w hen going from the
thumb to the finger throttle position
and the be st on e will be to the rider’s
preference and in direct relation with
the riding s tyle and con ditio ns .
mmo2015-008-102_a
THUMB THROTTLE POSITION : PUSH
DOWNWARD TO ROTATE THROTTLE
HOUSING
mmo2015-008-100_a
IF WANTED, CONTINUE TO ROTATE THE
THROTTLE HOUSING
mmo2015-008-101
FINGER THROTTL E POSITION
CAUTION
– It is HIGHLY recommended to use
gloves and NOT mitts when using
the finger throttle position.
– It is not recommended to use the
finger throttle position while rid-
ing in dense off trail areas.
The procedure to go back to the thumb
throttle position is the reverse of the
one shown above.
4) Brake Lever
Brake lever is located on the LH side of
handlebar.
When squeezed, the brake is applied.
When rele ased, it automatically re-
turns to its the rest position. Braking
effect is proportional to the pressure
appliedontheleverandtothetypeof
terrain and its snow coverage.
mmo2014-004-001_a
TYPICAL
1. Brake lever
2. To apply brake
5) Parking Brake Lever
Parking brake lever is located on the LH
side of handle bar.
Parking brake should be used when-
ever snowmobile is parked.
38
