CONTROLS, INSTRUMENTS AND EQUIPMENT
11) Tool Kit
A tool kit containing tools for basic
maintenance is supplied with the vehi-
cle.
The tool kit support is located in engine
compartment on pulley guard.
NOTICE
Make sure tool kit is prop-
erly secured to avoid c ontac t with
belt or pulley.
To remove the tool kit support from
the pulley gua rd , unlock the tab from
underneath the pulley guard and pull
the tool kit support towards front to
release it.
mmo2008-003-061_a
TYPICAL
1. Tool kit
12) Front and Rear
Bumpers
To be used whenever snowmobile re-
quires manual lifting.
CAUTION Use proper lif ting
techniques, notably using your legs
force. Do not attempt to lift either
end of the vehicle if it is above your
limits. U se appropriate lifting de-
vice or have assistance to share lift-
ing stress if possible.
mmo2009-004-014_a
TYPICAL
1. Front bumper
mmo2009-004-013_a
TYPICAL
1. Rear bumper
NOTICE
Do not use skis to pull or
lift snowmobile.
13) Gauge
WARNING
Never adjust or set functions on
the multifunction gauge while rid-
ing the vehicle, you could lose con-
trol.
