Skyjack SJ61T Service Manual

Telescopic Boom Series
Models SJ61T & SJ66T
194312
December 2007 Page 49
Section 3 - System Component Identification and Schematics Service and Maintenance
Index
No.
Skyjack
Part No.
Qty. Description
3.4 Hydraulic Schematic Parts List (Continued)
Parts list continued from previous page
CV1 166066 1 VALVE, Check (Auxiliary Pump)
CV2 159814 1 VALVE, Check (Main LS)
CV3 159814 1 VALVE, Check (Main LS)
CV4 159814 1 VALVE, Check (Main LS)
CV5 159814 1 VALVE, Check (Main LS)
CV6 159814 1 VALVE, Check (Main LS)
CV7 159814 1 VALVE, Check (Main LS)
CV8 159814 1 VALVE, Check (Main LS)
CV9 159814 1 VALVE, Check (Main LS)
CV10 159814 1 VALVE, Check (Main LS)
CV11 159814 1 VALVE, Check (Main LS)
CV12 159813 1 VALVE, Check (System Pump)
CV13 166065 1 VALVE, Check (Brake Manifold)
CV14 N/A 1 VALVE, Check (EPU)
CV15 159814 1 VALVE, Check (Generator LS)
CV16 159814 1 VALVE, Check (Generator LS)
CV17 168059 1 VALVE, Check (Generator)
CV18 168243 1 VALVE, Check (2 SPD)
DCV1 159817 1 VALVE, Check (Double, Steering)
DCV2 159817 1 VALVE, Check (Double, Platform Level)
DSV1 166062 1 COMPENSATOR (Swing)
DSV2 166061 1 COMPENSATOR (Boom Lift)
DSV3 166061 1 COMPENSATOR (Boom Extend)
EPU 160923 1 PUMP (Emergency)
F1 161932 1 FILTER (High Pressure)
F2 161933 1 FILTER (Return)
M1 163596 1 MOTOR (Axle Drive)
M2 N/A 1 MOTOR (Swing)
M3 144119 1 MOTOR (Generator, 3.5kW)
M4 N/A 1 MOTOR (Generator, 12kW)
MB1 162843 1 MANIFOLD (Main)
MB2 162844 1 MANIFOLD (Brake)
MB3 162497 1 MANIFOLD (Jib)
MB4 163541 1 MANIFOLD (No Jib)
MB5 166092 1 MANIFOLD (Jib Cylinder)
MB6 168158 1 MANIFOLD (Pressure Reducing)
MB7 168400 1 MANIFOLD (3.5kW Generator)
MB8 168401 1 MANIFOLD (12kW Generator)
OC1 160800 1 COOLER, Oil
OR1 166077 1 ORIFICE, 0.078" (Main Manifold)
OR2 166079 1 ORIFICE, 0.043" (Main Manifold)
OR3 166081 1 ORIFICE, 0.018" (Main Manifold)
OR4 166081 1 ORIFICE, 0.018" (Main Manifold)
OR5 166058 1 ORIFICE (Main Manifold)
OR6 166073 1 ORIFICE, 0.073" (Bleed Off)
OR7 168061 1 VALVE, Needle (3.5kw Generator)
Parts list continued on following page.
