Skyjack SJ61T Service Manual

Page 52 December 2007
Telescopic Boom Series
Models SJ61T & SJ66T
194312
Service and Maintenance Section 3 - System Component Identification and Schematics
Index
No.
Skyjack
Part No.
Qty. Description
3.5 Electrical Component Parts List
Parts list continued from previous page
2H-21A 143970 1 COIL, 12 Volt (Dump valve)
2H-42 143966 1 COIL, 12 Volt (Proportional ow enable)
2H-85 146079 1 COIL, 12 Volt (Optional generator valve)
3H-45 141409 1 COIL, 12 Volt (Motor 2-speed valve)
3H-26 141409 1 COIL, 12 Volt (Brake valve)
3H-65 141409 1 COIL, 12 Volt (Optional axle lock valve)
4H-13 143964 1 COIL, 12 Volt (Boom down valve)
4H-14 143964 1 COIL, 12 Volt (Boom up valve)
3H-15 143965 1 COIL, 12 Volt (Reverse drive valve)
3H-16 143965 1 COIL, 12 Volt (Forward drive valve)
4H-23A 143968 1 COIL, 12 Volt (Right steer valve)
4H-24A 143968 1 COIL, 12 Volt (Left steer valve)
4H-32 143964 1 COIL, 12 Volt (Left turret rotate valve)
4H-33 143964 1 COIL, 12 Volt (Right turret rotate valve)
4H-34 141421 1 COIL, 12 Volt (Jib down valve) (Model 66T)
4H-35 141409 1 COIL, 12 Volt (Jib up valve) (Model 66T)
4H-36 141409 1 COIL, 12 Volt (Platform right rotate valve)
4H-37 141421 1 COIL, 12 Volt (Platform left rotate valve)
4H-38 143964 1 COIL, 12 Volt (Telescope in valve)
4H-39 143964 1 COIL, 12 Volt (Telescope out valve)
4H-40 143969 1 COIL, 12 Volt (Platform level down valve)
4H-41 143969 1 COIL, 12 Volt (Platform level up valve)
A1 138225 1 JOYSTICK (Boom/turret)
A2 138224 1 JOYSTICK (Drive/steer)
A3 138226 1 CONTROLLER, Speed control selector
B1 144676 1 BATTERY, 12V (Wet)
BP1 103057 1 BEEPER, 4-28 VDC Slow pulsing (Platform control console)
BP2 103056 1 BEEPER, 7.5-16 VDC (Base control console) (ANSI/CSA)
BP3 144387 1 ALARM, Overload (CE)
CB1 117325 1 CIRCUIT BREAKER (15 Amp)
CB2 117325 1 CIRCUIT BREAKER (15 Amp)
CB3 117325 1 CIRCUIT BREAKER (15 Amp)
CB4 117326 1 CIRCUIT BREAKER (20 Amp)
CB5 141631 1 CIRCUIT BREAKER (50 Amp)
CB6 141630 1 CIRCUIT BREAKER (15 Amp)
DXX 102921 AR DIODE
FU1 138848 1 FUSE, 50 Amp
FS1 138230 1 SWITCH, Low fuel
H1 146652 1 HORN, 12 Volt
LB2 143971 1 LIGHT, Optional strobe
LB4 138806 1 LIGHT, Optional chassis
LB5 138806 1 LIGHT, Optional chassis
LS1 133075 1 LIMIT SWITCH, Direction sensing, N.O. held closed
LS2 144576 1 LIMIT SWITCH, High drive
LS3 144576 1 LIMIT SWITCH, High drive
M1 706921 1 PUMP, Emergency
PL1 138228 1 MODULE, Lower indicating
PL2 138229 1 MODULE, Upper indicating
Parts list continued on following page.
