Skyjack SJ61T Service Manual

Telescopic Boom Series
Models SJ61T & SJ66T
194312
December 2007 Page 53
Section 3 - System Component Identification and Schematics Service and Maintenance
Index
No.
Skyjack
Part No.
Qty. Description
3.5 Electrical Component Parts List (Continued)
Parts list continued from previous page
PL3 147229 1 LED BLOCK, Red (12 volts) (Base control console)
PL4 147229 1 LED BLOCK, Red (12 volts) (Platform control console)
R1 144523 1 RESISTOR, 7 ohm 25 W (Deutz D2011, GM and Kubota)
139088 1 RESISTOR, 6 ohm 25 W (Deutz TD2.9L)
R2 144714 1 RESISTOR, 12 ohm 25 W (SJ61T)
144714 1 RESISTOR, 15 ohm 25 W (SJ66T)
R3 163021 1 RESISTOR, 120 ohm 1/2 W
R4 164855 1 RESISTOR, 1.0k ohm 1/2 W
R5 164856 1 RESISTOR, 3.3k ohm 1/2 W
R6 164857 1 RESISTOR, 3.9k ohm 1/2 W (ANSI/CSA)
144492 1 RESISTOR, 380 ohm 1 W (CE & AS)
R7 143952 1 RESISTOR, 51 ohm 2 W (Deutz D2011, GM and Kubota)
151643 1 RESISTOR, 250 ohm 1 W (Deutz TD2.9L)
R8 151643 1 RESISTOR, 250 ohm 1 W
R9 151643 1 RESISTOR, 250 ohm 1 W
R10 151643 1 RESISTOR, 250 ohm 1 W
R11 151643 1 RESISTOR, 250 ohm 1 W
S1 119725 1 SWITCH, Main power disconnect
S2 138277 1 KEYSWITCH, Base/Off/Platform (Base control) (ANSI/CSA & AS Deutz D2011)
164833 1 KEYSWITCH, Base/Off/Platform (Base control) (ANSI/CSA Deutz TD2.9L)
144366 1 KEYSWITCH, Base/Off/Platform (Base control) (CE)
S3 147053 1 N.C. CONTACT, Emergency stop (Base control console)
S4 147053 2 N.C. CONTACT, Emergency stop (Platform control console)
S5 138278 1 SWITCH, Ignition/emergency pump toggle (Base control console)
S6 138278 1 SWITCH, Ignition/emergency toggle (Platform control console)
S7 102853 1 SWITCH, Function enable toggle (Base control console)
S8 102853 1 SWITCH, Diagnose toggle (Base control console) (Deutz engine)
S10 115747 1 SWITCH, Throttle toggle (Platform control console)
S11 154127 1 ASSEMBLY, Footswitch
S12 138278 1 SWITCH, Boom up/down toggle (Base control console)
S13 102853 1 SWITCH, Turret rotate toggle (Base control console)
S14 102853 1 SWITCH, Telescope in/out toggle (Base control console)
S15 102853 1 SWITCH, Platform leveling toggle (Base control console)
S16 102853 1 SWITCH, Platform rotate toggle (Base control console)
S17 102853 1 SWITCH, Jib up/down toggle (Base control console) (Model 66T)
S18 102853 1 SWITCH, Telescope in/out toggle (Platform control console)
S19 102853 1 SWITCH, Platform leveling toggle (Platform control console) (ANSI/CSA)
S20 102853 1 SWITCH, Platform rotate toggle (Platform control console)
S21 102853 1 SWITCH, Jib up/down toggle (Platform control console) (Model 66T)
S22 144266 1 SWITCH, Electrical generator (Platform control console)
S23 147054 1 N.O. CONTACT, Horn (Platform control console) (ANSI/CSA)
102853 1 SWITCH, Horn (Platform control console) (CE)
S24 115574 1 SWITCH, Optional lights (Platform control console)
S25 147054 1 N.O. CONTACT, Engine enable (Platform control console) (CE)
S26 102853 1 SWITCH, Fuel select (Platform control console) (GM engine)
S48 115574 1 SWITCH, Drive torque toggle (Platform control console)
TS1 166163 1 SWITCH, Tilt (analog 28°)
TT1 103336 1 HOUR METER
X22 138576 1 PORT, Diagnose (Deutz engine)
X23 138574 1 CONNECTOR, Engine (Deutz engine)
