180
Section 5 – Procedures Load Sensing System
Calibrate the Tare Point (No Load)
7. Press and release the actuation button twice, then press it a third time, this time holding it for about 3
seconds.
Result: A solid yellow LED light turns on, and the green LED will start to flash.
8. Press the actuation button.
Result: The green LED will flash quickly indicating the tare weight is being calibrated. Wait for the light to
stop flashing.
Calibrate Trip Point 1
9. The yellow LED will remain solid and the red LED will begin flashing.
10. Load the platform to the Trip Point 1 calibration point (see table below). Press the Actuation button.
Result: The red LED will flash quickly indicating that Trip Point 1 is being calibrated. Wait for the red LED to
stop flashing - this indicates that the calibration point has been stored.
Calibrate Trip Point 2
11. The yellow LED will remain solid and the red AND green LEDs will begin flashing.
12. Load the platform to the Trip Point 2 calibration point (see table below). Press the Actuation button.
Result: The Red and Green LEDs will flash quickly indicating that Trip Point 2 is being calibrated. Wait for
the Red and Green LEDs to stop flashing - this indicates that the calibration point has been stored.
13. The Red, Green, and Yellow LEDs will flash simultaneously for approximately 2 seconds. This indicates that
calibration is complete.
14. The Green LED will become solid, which is normal operating mode.
Model Trip Point 1 Trip Point 2
SJ86 T
244 kg
(538 lbs)
244 kg + 94 kg = 339 kg
(538 lbs + 210 lbs = 748 lbs)
