Skyjack SJ82 T Service Manual

46
SJ82 T, SJ86 T
229040ABA
Section 2 – Maintenance Tables and Diagrams Dimension and Reach Diagram - SJ82 T
2.15 Dimension and Reach Diagram - SJ82 TDiagram
BOOM R.O.M. - UP
72.5°
HORIZONTAL REACH @ MAX. HEIGHT
26’ 8”
[8.1 m]
MAX. PLATFORM HEIGHT
82’ [25.9 m]
MAX. WORKING HEIGHT
88’ [26.8 m]
8’ 9”
[2.67 m]
MAX. HORIZONTAL REACH
72’ 6” [22 m]
BOOM R.O.M. - DOWN
12°
7’ 3” [2.2 m]
CHASSIS GROUND
CLEARENCE
16” [0.40 m]
FRONT AXLE GROUND
CLEARANCE
13.25” [0.34 m]
INSIDE TURNING
RADIUS
245” [6.22 m]
AXLE
OSCILLATION
1°
GROUND
LEVEL
56” [1.42 m]
WIDTH
98” [2.5 m]
PLATFORM DEPTH
36” [0.9 m]
PLATFORM WIDTH
72” or 96”
[1.8m or 2.4 m]
TURRET ROTATION
360°
TAIL SWING
60” [1.5 m]
PLATFORM ROTATION
ANGLE
170°
PLATFORM
ROTATION
RADIUS
63.7” [1.62 m]
OUTSIDE TURNING
RADIUS
283” [7.18 m]
OVERALL RAILING
HEIGHT
53” [1.3 m]
PLATFORM RAILING
HEIGHT
44” [1.1 m]
PLATFORM HEIGHT
STOWED
19” [0.5 m]
STOWED LENGTH
37’ 10” [11.5 m]
WHEEL BASE
132” [3.3 m]
24” [0.61 m]
STOWED HEIGHT MIN.
118”
[3 m]
70
(21.34)
0 -5
(-1.52)
5
(1.52)
10
(3.05)
15
(4.57)
20
(6.10)
25
(7.62)
30
(9.14)
35
(10.67)
40
(12.19)
45
(13.72)
50
(15.24)
55
(16.76)
60
(18.29)
65
(19.81)
75
(22.86)
80
(24.38)
-10
(-3.05)
-15
(-4.57)
-5
(-1.52)
0
5
(1.52)
10
(3.05)
15
(4.57)
20
(6.10)
25
(7.62)
30
(9.14)
35
(10.67)
40
(12.19)
45
(13.72)
50
(15.24)
55
(16.76)
60
(18.29)
65
(19.81)
70
(21.34)
75
(22.86)
80
(24.38)
85
(25.91)
90
(27.43)
-10
(-3.05)
95
(28.95)
Feet (meters)
