Skyjack SJ82 T Service Manual

42
SJ82 T, SJ86 T
229040ABA
Section 2 – Maintenance Tables and Diagrams Specifications & Features - Dimensional Data
SJ82 T ANSI/CSA SJ86 T ANSI/CSA SJ86 T CE SJ86 T AS
Height & Reach
Working Height - Maximum 26.82 m 88' 28.04 m 92' 28.04 m 28.04 m
Platform Height - Maximum 24.99 m 82' 26.21 m 86' 26.21 m 26.21 m
Horizontal Reach - Maximum 22.1 m 72' 6" 23.41 m 76' 10" 23.41 m 23.41 m
Horizontal Reach at Maximum Height 8.15 m 26' 8" 8.61 m 28' 3" 8.61 m 8.61 m
Tailswing 1.52 m 60" 1.52 m 60" 1.52 m 1.52 m
Platform
Platform Size
0.9 x 2.4 m 36" x 96" 0.9 x 2.4 m 36" x 96" 0.91 x 2.44 m 0.91 x 2.44 m
0.9 x 1.8 m 36" x 72" 0.9 x 1.8 m 36" x 72" 0.91 x 1.83 m 0.91 x 1.83 m
Platform Rotation 170° 170° 170° 170° 170° 170°
Platform Rotation Radius 1.61 m 63-3/4" 1.62 m 64" 1.62 m 1.62 m
Platform Height - Stowed 0.48 m 19" 0.48 m 19" 0.28 m 0.28 m
Overall Railing Height 1.34 m 52-3/4" 1.34 m 52-3/4” 1.35 m 1.35 m
Platform Railing Height 1.09 m 43" 1.09 m 43" 1.12 m 1.12 m
Dimensional Data
Height Stowed 2.59 m 8'-6" 2.59 m 8'-6" 3 m 3 m
Length Stowed 11.52 m 37' 10" 12.34 m 40' 6" 12.95 m 12.95 m
Width 2.44 m 8' 2.44 m 8' 2.49 m 2.49 m
Wheelbase 3.35 m 11' 3.35 m 11' 3.35 m 3.35 m
Ground Clearance - Chassis 0.41 m 16" 0.43 m 17" 0.4 m 0.4 m
Ground Clearance - Front Axle 0.34 m 13-1/4" 0.36 m 14-1/4" 0.34 m 0.34 m
Axle Oscillation 0.04 m 1-3/4" 0.04 m 1-3/4" 1-3/4” 1-3/4”
Inside Turning Radius 6.10 m 19' 11" 6.20 m 20' 5" 6.20 m 6.20 m
Outside Turning Radius 7.18 m 23' 7" 7.20 m 23' 7" 7.20 m 7.20 m
Turret Rotation 360° 360° 360° 360° 360° 360°
Weight
Weight 17 055 kg 37,600 lb 17 145 kg 37,800 lb 17 550 kg 17 550 kg
2040AA
Table 2.11 Specifications & Features - Dimensional Data
