Skyjack SJ82 T - Dimension and Reach Diagram - SJ86 T

47
SJ82 T, SJ86 T
229040ABA
Dimension and Reach Diagram - SJ86 T Section 2 – Maintenance Tables and Diagrams
2.16 Dimension and Reach Diagram - SJ86 TDiagram
70
(21.34)
0 -5
(-1.52)
5
(1.52)
10
(3.05)
15
(4.57)
20
(6.10)
25
(7.62)
30
(9.14)
35
(10.67)
40
(12.19)
45
(13.72)
50
(15.24)
55
(16.76)
60
(18.29)
65
(19.81)
75
(22.86)
80
(24.38)
-10
(-3.05)
-15
(-4.57)
-5
(-1.52)
0
5
(1.52)
10
(3.05)
15
(4.57)
20
(6.10)
25
(7.62)
30
(9.14)
35
(10.67)
40
(12.19)
45
(13.72)
50
(15.24)
55
(16.76)
60
(18.29)
65
(19.81)
70
(21.34)
75
(22.86)
80
(24.38)
85
(25.91)
90
(27.43)
-10
(-3.05)
95
(28.95)
Feet (meters)
BOOM R.O.M. - UP 72.5°
HORIZONTAL REACH
@ MAX. HEIGHT
28’ 3” [8.6 m]
MAX. PLATFORM HEIGHT 86’ [26.2 m]
JIB R.O.M.
UP 65°
MAX. WORKING HEIGHT 92’ [28 m]
MAX. HORIZONTAL REACH 76’ 10” [23.4 m]
105”
[2.67 m]
BOOM R.O.M. - DOWN 12°
CHASSIS GROUND
CLEARENCE
16” [0.4 m]
JIB LENGTH 66” [1.7 m]
VERTICAL REACH
BELOW GRADE
10’ 8” [3.3 m]
FRONT AXLE GROUND
CLEARANCE
13.25” [0.34 m]
OUTSIDE TURNING
RADIUS 283” [7.18 m]
INSIDE TURNING
RADIUS 245” [6.22 m]
WIDTH 98” [2.5 m]
PLATFORM WIDTH
72” or 96”
[1.8 m or 2.4 m]
PLATFORM DEPTH
36” [0.9 m]
56” [1.42 m]
TURRET ROTATION 360°
PLATFORM ROTATION
RADIUS 63.7” [1.62 m]
PLATFORM ROTATION
ANGLE 170°
TAIL SWING
60” [1.5 m]
AXLE
OSCILLATION 1°
GROUND
LEVEL
WHEEL BASE 132” [3.35 m]
24”
[0.61 m]
JIB R.O.M.
DOWN 60°
PLATFORM HEIGHT
STOWED 11” [0.28 m]
OVERALL RAILING
HEIGHT 53” [1.35 m]
PLATFORM RAILING
HEIGHT 44” [1.12 m]
486” [12.34 m]
120”
[3.05 m]
