Skyjack SJ82 T Service Manual

A B C D E F G H
V
Z
Y
X
W
87
SJ82 T, SJ86 T
229040ABA
3.30 Dual Capacity Sensing Module
M167280AE
NOTES :
1. OPERATING VOLTAGE 8 - 18 VDC
2. OPERATING TEMPERATURE -40C TO 70C
3. CONFORMAL COATED PCB WITHIN A PLASTIC HOUSING
4. 08-PIN TE CONNECTOR OR SIMILAR.
+12VDC
LS5
0V
PL1-500LB
PL2-OVERLOAD
LS4
SUPPLY(+)
DIN1
DIN2
SUPPLY(-)
DOUT1
DOUT2
AIN2 (4-20mA)
AIN1 (4-20mA)
DOUT3
SCOUT1SCIN1
SAFETY CONTACTS (3AMP)
LOAD ZONE BORDER
SIGNALSIGNAL
LOAD REDUNDANT
SCOUT2SCIN2
SCOUT3SCIN3
FROM BOOM JOYSTICK & TOGGLE
FROM EXTENSION TOGGLES
FROM WIRE 09
TO BOOM DOWN SOLENOID
TO EXTENSION SOLENOID
TO SYSTEM PRESSURE ENABLE
TO BOOM DOWN BYPASS RELAYS
OK
LIGHT
BP3-OVERLOAD
