Skyjack SJ82 T Service Manual

33
SJ82 T, SJ86 T
229040ABA
MEWP Torque Specifications Section 2 – Maintenance Tables and Diagrams
Location Description Torque (ft-lb) Torque (Nm)
Base
Trunnion Mount BOLT, Hex head (3.4"-10 x 4.5", Grade 8) 210 285
Rear Axle Mount BOLT, Hex head (M20 x 2.5 120mm, Grade 10.9) 210 285
Oscillating Axle Mount BOLT, Hex head (M20 x 2.5 120mm, Grade 10.9) 280 380
Lockout Cylinder Pin BOLT, Hex head (3/8"-16 x 1", Grade 5) 23 31
Swing Drive Motor BOLT, Hex head (3/4"-10 x 2", Grade 8) 280 380
Rotation Gear BOLT, Hex head (3/4"-10 x 5", zinc, Grade 8) 280 380
Hydraulic Drive Motor BOLT, Hex head (M14 x 2 x 30mm, ZP, Grade 8.8) 80 108
Wheel Nut NUT, Wheel 247-302 335-410
Turret
Rotation Gear BOLT, Hex head (3/4"-10 x 4", zinc, Grade 8) 280 380
Engine
Deutz Engine Mount BOLT, Hex head (1/2"-13 x 3.75", Grade 5) 55 75
Coupling Assembly BOLT (M10) 40 55
Muffler NUT 40 55
Engine
Deutz Engine Mount BOLT, Hex head (1/2"-13 x 3.75", Grade 5) 55 75
Coupling Assembly BOLT (M10) 40 55
Muffler NUT 40 55
Cylinders
Jib ROD NUT 347 470
Platform
Rotary Mount
BOLT, Hex head, patch (3/8"-16 x 7/8", zinc, Grade 8) 35 48
BOLT, Hex head (1"-8 x 10.5", zinc, Grade 8) 480 569
Rotary Manifold BOLT, Hex head (1/2"-13 x 2", Grade 8) 80 108
Rotary Actuator BOLT, Hex head (3/4"-10 x 3", Grade 8) 210 285
Load Cell Mounting
BOLT, Hex head patch (ZP, M16 x 1.5 x 4.5", Grade 8.8) 130 177
BOLT, Hex head (1/2"-13 x 2.25", Grade 8) 80 108
Special Options
Generator Support BOLT, Hex head (1/2”-13 x 2”, Grade 8) 55 75
Oil Cooler Support BOLT, Hex head (1/2”-13 x 2”, Grade 8) 55 75
1394AA
Table 2.2 MEWP Torque Specifications
