Skyjack SJ82 T Service Manual

54
SJ82 T, SJ86 T
229040ABA
Section 3 – System Component Identification and Schematics Hydraulic Parts List
Index
No.
Skyjack
Part No.
Description
2H-19 171435 VALVE, Control - lift cushion flow
2H-21A 159805 VALVE, Control - pressure dump
2H-42 168755 VALVE, Control - flow enable
2H-85 168056 VALVE, Control - flow enable, 12 kW generator
2H-85 168056 VALVE, Control - flow enable, 3.5 kW generator
3H-26 159827 VALVE, Control - brake release
3H-45 159827 VALVE, Control - 2-Speed
3H-65 159827 VALVE, Control - axle lock out
3H-V1 N/A VALVE, Control - pressure compensator
3H-V2 N/A VALVE, Control - load sense compensator
4H-13 168756 VALVE, Control - boom up
4H-14 168756 VALVE, Control - boom down
4H-15 N/A VALVE, Control - drive pump control reverse
4H-16 N/A VALVE, Control - drive pump control forward
4H-34 166036 VALVE, Control - jib down
4H-35 166036 VALVE, Control - jib up
4H-36 168757 VALVE, Control - platform rotate left
4H-37 168757 VALVE, Control - platform rotate right
4H-38 168758 VALVE, Control - boom retract
4H-39 168756 VALVE, Control - boom extend
4H-40 159803 VALVE, Control - platform level down
4H-41 159803 VALVE, Control - platform level up
5H-23A 159807 VALVE, Control - steer right
5H-24A 159807 VALVE, Control - steer left
5H-32 159806 VALVE, Control - swing right
5H-33 159806 VALVE, Control - swing left
C1 165079 CYLINDER, Boom lift
C2 165080 CYLINDER, Boom extend
C3 165081 CYLINDER, Master
C4 165082 CYLINDER, Slave
C5 165083 CYLINDER, Jib
C6 212871 CYLINDER, Axle lock
C7 1212871 CYLINDER, Axle lock
C8 170903 CYLINDER, Steer
C9 N/A CYLINDER, Brake - front
C10 N/A CYLINDER, Brake - rear
CB1 171421 VALVE, Counterbalance - swing drive
CB2 171421 VALVE, Counterbalance - swing drive
CB3 159841 VALVE, Counterbalance - boom lift
CB4 165486 VALVE, Counterbalance - boom extend
CB5 165486 VALVE, Counterbalance - boom extend
CB6 159841 VALVE, Counterbalance - platform level
CB7 159841 VALVE, Counterbalance - platform level
CB8 159841 VALVE, Counterbalance - jib
CB9 159841 VALVE, Counterbalance - jib
CB10 141399 VALVE, Counterbalance - platform rotate
3.5 Hydraulic Parts List
