53
Wire Numbers and Color Codes - Additional Section 3 – System Component Identification and Schematics
3.4 Wire Numbers and Color Codes - Additional
AC Cord Color Code
(Battery Charger & Platform Power Outlet)
Standard Definition NEC Colors IEC Colors
Protective Ground/Protective Earth Green Green/Yellow
Neutral White Blue
Line, Single Phase Black Black or Brown or Grey
1789AA
Note: Standard colors referenced from IEC 60445:2010, Annex A: Table 1.
1790AA
Load Cell Color Code
Wire No. Wire Color Wire No. Wire Color Wire No. Wire Color Wire No. Wire Color
02 Brown 60 Yellow 161 White unused Beige
02 Blue 60 Red 162 Green unused Purple
unused Black
