SJ82 T, SJ86 T
229040ABA
3.22 Limit Switch Connections
M63752AA
Black
09
Black/White
17
09
17
LS1 - Direction Sensing Limit Switch
Black
09
Black/White
29
29
09
LS2 - High Speed / Tilt Override Limit Switch
Black/WhiteBlack
29 59
29
59
LS3 - Fly In Limit Switch
Black
09
Black
09B
Black/White
121
09
121
09B
(ANSI)(CE)
LS4 - Boom Angle (Dual Load) Limit Switch
Black/WhiteBlack
09 122
Black/White
(ANSI) (CE)
121
09
122 121
LS5 - Boom Extension (Dual Load) Limit Switch
Black/WhiteBlack
09 19
09
19
LS6 - Lift Cushion Limit Switch
