Skyjack SJ82 T - Check the Swing Drive Oil; Change the Swing Drive Oil

213
SJ82 T, SJ86 T
229040ABA
Turret Section 5 – Procedures
5.5-3 Check the Swing Drive Oil
1. Remove the plug from the fill port
1
on the
back of the swing drive.
2. Check the oil level. The oil level should be
slightly below the port threads.
3. Add oil if needed. Refer to 2.10 Hydraulic
Specifications & Gear Oil for recommended oil
types.
5.5-4 Change the Swing Drive Oil
NOTE
The oil change must be performed on a flat, level
surface.
1. Remove the plug from the fill port
1
.
2. Place a suitable container under the drain
port
2
.
3. Remove the plug from the drain port.
4. Allow the oil to drain.
5. Reinstall the drain plug.
6. Refill the swing drive with approximately 32 oz
(1 L) of oil (refer to 2.10 Hydraulic Specifications
& Gear Oil for recommended oil types).
7. Reinstall the plug at the fill port.
1
2
1
