52
Section 3 – System Component Identification and Schematics Wire Number and Color Code
WIRE
NO.
WIRE
COLOR
WIRE
NO.
WIRE COLOR
WIRE
NO.
WIRE
COLOR
WIRE
NO.
WIRE
COLOR
WIRE
NO.
WIRE
COLOR
00 WHT 20 ORG/BLU 44 YEL/WHT 67 ORG/BRN 92 GRN SHLD
000 WHT 21 WHT/RED 45 YEL/ORG 68 GREY 93 BLK SHLD
B1 BLU/PINK 23 BLK/WHT 46 RED/BLK 69 WHT/GRN 95 YEL/GREY
01 PUR/BLK 24 BLU/BLK 47 PUR/ORG 70 ORG/PINK 96 WHT/GREY
02 WHT 25 BRN/BLK 48
YEL/GREY
71 RED/ORG 97 ORG/GREY
03 GRN/PUR 26 BLU/YEL 49 GRN/RED 72 RED/BRN 98 RED SHLD
04 RED/YEL 27 RED/BLK/WHT 50 BRN 73 RED/PINK 98A BLK SHLD
05 PUR 28 GRN 51 BLK/GRN 74
GRN/
GREY
99 BLK/GREY
06 29 GREY/ORG 52 GRN/BLU 75 GREY/PUR 103 BLK/PUR
07 RED 30 RED/GRN 53 BRN/RED 76 BRN/BLU 104 GRN/ORG
08 PUR/WHT 31 RED/WHT 54 PUR/RED 77 BRN/GREY 105 GRN/BRN
09 YEL 32 GRN/BLK 55 YEL/PUR 78 RED/BLU 106 GRN/PINK
10 BLU/WHT 33 GRN/WHT 56 YEL/BLK 79 BRN/PUR 107 BLK/BLU
11 WHT/ORG 34 ORG/BLK 57 BRN/GRN 80
GREY/
WHT
108 YEL/BRN
12
RED/YEL/
BLK
35 ORG/WHT 58 WHT/PUR 81 GREY/BLK 109 GRN/YEL
13 ORG 36 RED/PUR 59 YEL/BLU 82 BRN/WHT 110A BLU
14 BLK 37
WHT/RED/
BLK
60 WHT/BLU 83 BLU/GREY 110B BRN
15 BLU 38 ORG/RED 61 GREY/BRN 84
WHT/BLK/
PUR
111 GREY/GRN
16 WHT/BLK 39 BLK/RED 62 GREY/RED 85 GREY/BLU 112 BLU/ORG
17 BLU/GRN 40 BLU/RED 63 GREY/YEL 86/87 PUR/BLU 113 BLU/BRN
18 GRN/BLU 41 BLU/PUR 64 WHT/BRN 88 BLK/ORG 114 YEL/RED
19 ORG/GRN 42 PINK 65 YEL/PINK 90 RED/GREY 115 WHT/PUR
22 PUR/GRN 43 WHT/YEL 66 ORG/YEL 91 RED SHLD 118 PUR/PINK
3.3 Wire Number and Color Code
This table is to be used as a wire number/color reference for all electrical drawings and schematics. All wire
numbers will retain their origional color coding, for example if wire 7 is red, wire 7A, 7B, and 7C will also be red.
