55
Hydraulic Parts List Section 3 – System Component Identification and Schematics
Index
No.
Skyjack
Part No.
Description
CB11 141399 VALVE, Counterbalance - platform rotate
CB12 212872 VALVE, Counterbalance - axle lock
CB13 212872 VALVE, Counterbalance - axle lock
CB14 171388 VALVE, Counterbalance - lift cylinder
CV1 171389 VALVE, Check - main inlet
CV2 171410 VALVE, Check - auxiliary pump
CV3 171411 VALVE, Check - steer load sense
CV4 159815 VALVE, Check - main LS
CV5 159815 VALVE, Check - main LS
CV6 171412 VALVE, Check - swing drive load sense
CV7 171412 VALVE, Check - main boom load sense
CV8 171412 VALVE, Check - extension load sense
CV9 159815 VALVE, Check - main LS
CV10 159815 VALVE, Check - main LS
CV11 171411 VALVE, Check - level override load sense
CV12 141712 VALVE, Check - pilot pressure
CV13 171413 VALVE, Check - brake manifold
CV14 N/A VALVE, Check - EPU
CV16 N/A VALVE, Check - 3.5 kW generator
CV17 159814 VALVE, Check - 12 kW generator manifold LS
CV18 171410 VALVE, Check - 12 kW generator manifold
CV19 N/A VALVE, Check - 12 kW generator
CV20 159814 VALVE, Check - 3.5 kW generator LS
DSV1 166062 COMPENSATOR, Swing
DSV2 171417 COMPENSATOR, Boom lift
DSV3 171417 COMPENSATOR, Boom extend
EPU 168672 PUMP, Emergency
F1 161932 FILTER, High pressure
F2 161933 FILTER, Return
FR1 166058 FLOW REGULATOR, Pressure-compensated
M1 171944 MOTOR, Drive - axle
M2 170930 MOTOR, Swing
M3 171419 MOTOR, Generator - 3.5 kW
M4 171438 MOTOR, Generator - 12 kW
MB1 165487 MANIFOLD, Main
MB2 216511 MANIFOLD, Brake
MB3 168661 MANIFOLD, Jib
MB4 163541 MANIFOLD, No jib
MB5 168618 MANIFOLD, 3.5 kW generator
MB6 171437 MANIFOLD, 12 kW generator
OC1 160800 COOLER, Oil
OR1 171414 ORIFICE, 0.090" - main manifold
OR2 171415 ORIFICE, 0.055” - main manifold
OR3 171416 ORIFICE, 0.020” - main manifold
OR4 171416 ORIFICE, 0.020” - main manifold
OR5 171416 ORIFICE, 0.020” - main manifold
OR6 171416 ORIFICE, 0.020” - main manifold
