56
SJ82 T, SJ86 T
229040ABA
Section 3 – System Component Identification and Schematics Hydraulic Parts List
Index
No.
Skyjack
Part No.
Description
OR8 171422 ORIFICE, 0.035” - main manifold
OR9 171420 ORIFICE, 0.073” - bleed off
OR10 171450 VALVE, Flow regulator - 3.5 kW generator
OR11 171450 VALVE, Flow regulator - 12 kW generator
P1 169006 PUMP, Hydrostatic
P1A 154119 PUMP, Charge
P2 165101 PUMP, System
PR1 216235 VALVE, Pressure reducing
QD1 122420 QUICK DISCONNECT
RA1 144710 ACTUATOR, Rotary - platform - SJ86 T
RA2 167073 ACTUATOR, Rotary - turret
RA3 165466 ACTUATOR, Rotary - platform - SJ82 T
RV1 168759 VALVE, Relief - main manifold
RV2 171385 VALVE, Relief - swing drive
RV3 166047 VALVE, Relief - platform level
RV4 171386 VALVE, Relief - boom extend
RV5 N/A VALVE, Relief - brake manifold
RV6 N/A VALVE, Relief - drive
RV7 N/A VALVE, Relief - drive
RV8 N/A VALVE, Relief - charge
SV1 141414 VALVE, Shuttle - brake manifold
SV2 166054 VALVE, Shuttle - brake manifold
SV3 159803 VALVE, Shuttle - main manifold
SV4 N/A VALVE, Shuttle - swing drive brake
V1 141436 VALVE, Control - brake release override
V2 166053 VALVE, Control - loop flush
V3 159831 VALVE, Control - brake hand pump
V4 171387 VALVE, Control - pilot operated
V5 171387 VALVE, Control - pilot operated
V6 221775 VALVE, Control - pilot operated
V7 221776 VALVE, Control - pilot operated
V8 166053 VALVE, Control - loop flush
