SJ82 T, SJ86 T
229040ABA
Deutz Diesel Engines Section 5 – Procedures
5.6-6 Deutz TD2.9L Fault Codes
Code SPN FMI Blink Code Error Identification
1677 524106 9 1-9-5 Timeout error of CAN-Receive-Frame ComRxEGRMsFlw1 (EGR actuator)
1678 524107 9 9-3-1 Timeout error of CAN-Receive-Frame ComRxEGRMsFlw2 (EGR actuator).
1679 524109 9 9-3-3 Timeout error of CAN-Receive-Frame ComRxEGRTVActr (EGR actuator).
1680 524111 9 9-3-5 Timeout error of CAN-Receive-Frame ComRxETVActr.
1681 524113 9 9-3-7 Timeout error of CAN-Receive-Frame ComRxITVActr.
1682 524120 9 9-4-4 Timeout error of CAN-Receive-Frame ComRxSCRHtDiag.
1683 524121 9 9-4-5 Timeout error of CAN-Receive-Frame ComRxTrbChActr (wastegate actuator).
1684 524122 9 9-4-6 Timeout error of CAN-Receive-Frame ComRxUQSens (Urea quality).
1685 524123 9 9-4-7 Timeout error of CAN-Receive-Frame ComSCRHtCtl.
1686 524124 9 9-4-8 Timeout error of CAN-Receive-Frame ComTxAT1IMG.
1687 524125 9 9-4-9 Timeout error of CAN-Receive-Frame ComTxTrbChActr (Wastegate actuator).
1698 524133 2 9-5-6 HMI system; set if restore button blocked.
1699 524134 0 9-5-7 DPF, ash load exceeds the shutoff threshold.
1700 524134 0 9-5-7 DPF, ash load exceeds the warning threshold.
1701 524135 0 9-5-8 DPF, soot load exceeds the shutoff threshold.
1702 524135 14 9-5-8 DPF, soot load exceeds the service request threshold.
1703 524135 0 9-5-8 DPF, soot load exceeds the warning threshold.
1705 524156 9 9-7-2 Timeout error of CAN-Receive-Frame ComRxEBC2.
1706 524157 9 9-7-3 Fan control; time out for fan governing.
1708 524159 0 9-7-5 Fan; short circuit battery or open load.
1709 524159 1 9-7-5 Fan; short circuit ground.
1710 524160 5 9-7-6 Fan; in/outlet valve 1; open load.
1712 524160 3 9-7-6 Fan; in/outlet valve 1; short circuit battery.
1713 524160 4 9-7-6 Fan; in/outlet valve 1; open load ground.
1714 524161 5 9-7-7 Fan; in/outlet valve 2; open load.
1716 524161 3 9-7-7 Fan; in/outlet valve 2; short circuit battery.
1717 524161 4 9-7-7 Fan; in/outlet valve 2; open load ground.
1718 524162 12 9-7-8 Fan; fancontrol; angle sensor defect.
1719 524163 12 9-7-9 Fan; fancontrol; fan or valve defect.
1752 2791 7 4-1-5 EGR actuator, actuator blocked.
1753 2791 2 4-1-5 EGR actuator, CAN error.
1754 2791 13 4-1-5 EGR actuator, EOL calibration error.
1755 2791 12 4-1-5 EGR Actuator, internal electrical fault.
1756 2791 13 4-1-5 EGR actuator, learning process aborted.
1757 2791 6 4-1-5 EGR actuator current is above maximum threshold.
1758 2791 3 4-1-5 EGR actuator supply voltage is above the maximum threshold.
