Platform Section 5 – Procedures
5.1-6 Check I/O Error
If a fault is detected, the engine shuts off and the SCM displays “Check I/O Err? Press select”.
This check helps to determine which channel has the fault.
Use the chart below to determine which function each channel is related to. A properly working channel is
indicated by a “0”. A fault is indicated by a “1”.
Check IO Err?
PRESS SELECT
SAVE
EXIT
PE 1 2 3 4 5
0 0 0 0 0

+

–
MENU
SELECT
PE 6 7 8 9 10
0 0 0 0 0
PE 11 12 13 14 15
0 0 0 0 0
DRIVE REV
1
DRIVE FWD
2
ROTATE L
3
ROTATE R
4
BOOM DOWN
5
BOOM UP
6
RISER DN
7
RISER UP
8
FLY OUT
9
FLY IN
10
JIB DOWN
11
JIB UP
12
PLATF RGT
13
PLATF LFT
14
PROP FLOW
15
Channel Functions
Example:
This example indicates an
error (1) in channel 7,
which is the Riser Down
function.
PE 6 7 8 9 10
0 1 0 0 0
