Skyjack SJ85 AJ Service Manual

54
SJ85 AJ229044ADA
Section 3 – System Component Identification and Schematics Hydraulic Parts List
3.5 Hydraulic Parts List
Index
No.
Skyjack
Part No.
Description
OC1 160800 OIL COOLER
2H-21A 102626 VALVE, Dump
2H-42C 168755 VALVE, Flow enable platform/jib
2H-85 168058 VALVE, Flow enable - 12 kW generator
2H-85 168056 VALVE, Flow enable - 3.5 kW generator
3H-165 159827 VALVE, Diff. lock
3H-26 159827 VALVE, Brake release
3H-45 159827 VALVE, 2-spd
3H-65 159827 VALVE, Axle lock out
4H-13 168758 VALVE, Boom up
4H-14 168758 VALVE, Boom down
4H-15 N/A VALVE, Drive pump control
4H-16 N/A VALVE, Drive pump control
4H-30 212555 VALVE, Riser down
4H-31 212555 VALVE, Riser up
4H-34 166041 VALVE, Jib down
4H-35 166041 VALVE, Jib up
4H-36 166041 VALVE, Platform rotate left
4H-37 166041 VALVE, Platform rotate right
4H-38 168756 VALVE, Boom in
4H-39 168758 VALVE, Boom out
4H-40 159803 VALVE, Platform level down
4H-41 159803 VALVE, Platform level up
5H-23A 208875 VALVE, Steer right
5H-24A 208875 VALVE, Steer left
5H-32 159806 VALVE, Rotate left
5H-33 159806 VALVE, Rotate right
C1 197887 CYLINDER, Boom lift
C2 198250 CYLINDER, Boom extend
C3 197888 CYLINDER, Master
C4 197889 CYLINDER, Slave
C5 165083 CYLINDER, Jib
C6 212872 CYLINDER, Axle lock
C7 212872 CYLINDER, Axle lock
C8 170903 CYLINDER, Steer
C9 N/A CYLINDER, Brake - front
C10 N/A CYLINDER, Brake - rear
CB1 171421 VALVE, Counterbalance - swing drive
CB2 171421 VALVE, Counterbalance - swing drive
CB3 212623 VALVE, Counterbalance - boom lift
CB4 165486 VALVE, Counterbalance - boom extend
CB5 165486 VALVE, Counterbalance - boom extend
CB6 159841 VALVE, Counterbalance - platform level
CB7 159841 VALVE, Counterbalance - platform level
CB8 216059 VALVE, Counterbalance - jib
CB9 216059 VALVE, Counterbalance - jib
