Skyjack SJ85 AJ Service Manual

144
SJ85 AJ229044ADA
Section 5 – Procedures Platform
5.1-4 SCM Operating Values Chart
25
26
27
28
30
31
29
34
35
33
32
1
2
3
4
5
7
8
6
11
12
10
9
13
14
15
16
18
17
19
20
23
22
21
24
P3
25
26
27
28
30
31
29
34
35
33
32
1
2
3
4
5
7
8
6
11
12
10
9
13
14
15
16
18
17
19
20
23
22
21
24
P2
P1
1
2
3
5
4
6
7
8
9
14
13
12
11
10
P1 (Black)
Pin Wire Function Input/Output Type IO Name Label Expected Value
1 04 POWER VS1 12V
2 04 POWER VS2 12V
3 04 POWER VS3 12V
4 04 POWER VS4 12V
5 N/U
6 N/U
7 N/U
8 N/U
9 N/U
10 02 GROUND GND1 0V
11 02 GROUND GND2 0V
12 02 GROUND GND3 0V
13 02 GROUND GND4 0V
14 N/U
