2.10 Specifications & Features - Dimensional DataTable
SJ85 AJ
Height and
Reach Data
Working Height - maximum 27.66 m 91' 9"
Platform Height - maximum 25.83 m 84' 9"
Horizontal Reach - maximum 17.22 m 56' 3"
Horizontal Reach - at maximum height 7.62 m 25'
Horizontal Reach - at flyboom retracted 10.52 m 34' 6"
Tailswing 0.86 m 2' 10"
Up and Over Clearance - at platform 9.55 m 31' 4"
Up and Over Clearance - at main boom 10.24 m 33' 7"
Platform
Data
Platform Size
0.91 x 2.44 m 36" x 96"
0.91 x 1.83 m 36" x 72"
Platform Rotation 168° 168°
Platform Rotation Radius 1.62 m 64"
Platform Height - stowed 0.28 m 11"
Overall Railing Height 1.35 m 53"
Platform Railing Height 1.12 m 44"
Dimensional
Data
Height - stowed min. 2.67 m 8' 9"
Stowed length @ min. height 11.63 m 38' 2"
Stowed length - min. 10.03 m 32' 11"
Width 2.49 m 8' 2"
Wheelbase 2.84 m 9' 4"
Ground Clearance (Chassis) 0.41 m 16"
Ground Clearance (Front Axle) 0.33 m 13"
Axle Oscillation 0.06 m° 2-1/2"
Turning Radius - Inside 3.05 m 10'
Turning Radius - Outside 6.22 m 20' 5"
Turret Rotation 360° 360°
Jib Data
Jib Length 1.68 m 5' 6"
Jib Range of Motion - vertical 2.97 m 9' 9"
Jib Range of Motion - down 60° 60°
Jib Range of Motion - up 65° 65°
1764AB
