Deutz Diesel Engines Section 5 – Procedures
5.6-6 Deutz TD2.9L Fault Codes
Code SPN FMI Blink Code Error Identification
8 132 1 2-2-6
The air mass flow AFS_dm is greater than or equal to AFS_PhysRng.Min_C.
Physical range check is low for air mass flow sensor.
9 172 2 2-2-6 Air inlet filter temperature, plausibility error.
26 523891 14 2-6-3
When AirHt_ctDefSRCLoOn_mp is lower than AirHt_ctMaxDef_C.
DFC to SRC Low error when heater is on.
28 523953 2 7-2-8
Healing takes place if the condition for error detection is not present.
Air temperature monitoring plausibility check array.
30 523955 2 7-2-8
Healing takes place if the condition for error detection is not present.
Air temperature monitoring plausibility check array.
36 523923 3 7-2-9
37 523924 3 1-6-7 Short circuit to battery error of actuator relay 2.
38 523925 3 7-3-1 Short circuit to battery of actuator relay 3.
40 523927 3 7-3-3 Short circuit to battery of actuator relay 6.
41 523923 4 7-2-9
Short circuit to ground error.
Detailed information not available.
42 523924 4 1-6-7 Short circuit to ground of actuator relay 2.
43 523925 4 7-3-1 Short circuit to ground of actuator relay 3.
44 523926 4 7-3-2 Short circuit to ground of actuator relay 4.
45 168 3 3-1-8 Sensor battery voltage error; signal range check is high.
46 168 4 3-1-8 Sensor battery voltage error; signal range check is low.
47 168 2 3-1-8 High battery voltage; warning threshold is exceeded.
48 168 2 3-1-8 High battery voltage; Shot off threshold exceeded.
55 523910 14 6-9-5
Air pump doesn’t achieve air mass flow setpoint. Burner Control - burner air
pump.
56 524013 7 8-5-6
Burner Control. Burner does not start after several trials (burner flame lost
detection).
Burner flame unintentional deleted.
57 524020 14 8-6-3
Burner Control: Power reduction due to low lambda. Engine power: Not
enough oxygen for regeneration.
58 523911 0 7-2-3 Burner dosing valve (DV2); Overcurrent at the end of the injection phase.
59 523911 12 7-2-3 Burner dosing valve (DV2); Powerstage over temperature.
60 523911 3 7-2-3 Burner dosing valve (DV2); Short circuit to battery.
62 523911 4 7-2-3 Burner dosing valve (DV2); Short circuit to ground.
63 523911 11 7-2-3 Burner dosing valve (DV2); Short circuit high side powerstage.
64 523912 2 7-2-2 Burner dosing valve (DV2) downstream pressure sensor; plausibility error.
66 523912 0 7-2-2
Physical range check high for burner dosing valve (DV2) downstream
pressure; Shut off regeneration.
