38
2.7 MEWP Torque SpecificationsTable
Location Description
Torque (ft-lb) Torque (Nm)
Base
Front Axle Mount (Trunnion) BOLT, Hex head (3/4"-10 x 5", Grade 8) 210 285
Rear Axle Mount (U-Bolt) NUT, Torque lock (3/4"-10, Grade C) 210 285
Axle Lock Cylinder Mount BOLT, Hex head (1/2"-13 x 1.75", Grade 8) 95 129
Axle Drive Motor Mount BOLT, Hex head (M14 x 2 x 35mm, Grade 10.9) 150 203
Wheel Nut NUT, Wheel 247-302 335-410
Rotation Gear BOLT, Hex head (3/4"-10 x 5", Grade 8) 280 380
Turret
Rotation Gear BOLT, Hex head (3/4"-10 x 4", Grade 8) 280 380
Swing Drive Motor BOLT, Hex head (3/4"-10 x 2", Grade 8) 280 380
Engine
Engine Mount BOLT, Hex head (1/2"-13 x 3.25", Grade 5) 62 84
Coupling Assembly - Deutz/Kubota BOLT, Socket head (M10) 40 55
Coupling Assembly - Perkins
BOLT, Socket head (M10-1.5 x 20) 18 24
BOLT, Hex head (3/8"-16 x 1") 40 55
Cylinders
Jib ROD NUT 312-382 423-518
Slave PISTON 596-728 808-987
Extension PISTON 440-538 597-729
Master PISTON 802-818 1087-1109
Lift PISTON 1058-1293 1434-1753
Riser PISTON 810-990 1098-1342
Platform
Rotary Actuator Mount
BOLT, Hex head, patch (3/8"-16 x 7/8", Grade 8) 35 48
BOLT, Hex head (1"-8 x 10.5", Grade 8) 480 569
Rotary Manifold BOLT, Hex head (1/2"-13 x 2", Grade 8) 80 108
Load Cell Mounting
BOLT, Hex head patch (M16 x 1.5 x 4.5", Grade 8.8) 130 177
BOLT, Hex head (1/2"-13 x 2.5", Grade 8) 80 108
1711AA
