Skyjack SJ85 AJ Service Manual

A B C D E F G H
V
Z
Y
X
W
71
SJ85 AJ
229044ADA
3.17 Engine Control Wiring - Deutz TD2.9L
M198135AG
78
90
99A
02
77CR1 78CR
00A 79
90
99B
02
79CR
76A
76
02
76B
76ACR
54
03A
56B
56A
56ACR
60
60
77
104 105
02 02
99 99B
99A 90
00A 03A
57A
74
76
77
78
79
81
60
02
60
90
R6=3.9k
R4=1.0k
R5=3.3k
R3=120
(+)
(-)
104 105
99 99B 99A 90
R3=120
R5=3.3k
R6=3.9k
R4=1.0k
09A
60
00A
60
02
00A1
00A1CR
60
J2
J1
TO ENGINE
HARNESS
103A
103
103A
DIAGNOSE
S1
105
104
B
G
H
A
60
02
56A
56B
57A
103
103A
105
104
74
54
00A
81
76B
90
99
76A
09A
68
DETAIL A
RESISITOR
PLACEMENT
J4
J3
96
84
CANH
CANL
CONNECTOR J1
PIN 1 - 103
PIN 2 - 103A
PIN 3 - 56B
PIN 4 - 56A
PIN 5 - 84
PIN 6 - CANH
PIN 7 - PLUGGED
PIN 8 - 57A
PIN 9 - CANL
PIN 10 - 74
PIN 11 - 105
PIN 12 - 104
CONNECTOR J2
SOCKET 1 - 76B
SOCKET 2 - 96
SOCKET 3 - 76A
SOCKET 4 - 99
SOCKET 5 - 90
SOCKET 6 - JUMPER WITH SOCKET 7
SOCKET 7 - JUMPER WITH SOCKET 6
SOCKET 8 - 68
SOCKET 9 - 54
SOCKET 10 - 81
SOCKET 11 - 00A
SOCKET 12 - 09A
X22 CONN.
A - 09
B - 02
G - 105
H - 104
60
76
CONNECTOR J3
PIN 1 - 03A
PIN 2 - 77
PIN 3 - 81
PIN 4 - 84
PIN 5 - 96
PIN 6 - 76
PIN 7 - 74
PIN 8 - 57A
PIN 9 - PLUGGED
PIN 10 -68
PIN 11 -CANL
PIN 12 -CANH
CONNECTOR J4
PIN 1 - 60
PIN 2 - 00A1
PIN 3 - PLUGGED
PIN 4 - 79
PIN 5 - 78
PIN 6 - 02
PIN 7 - PLUGGED
PIN 8 - PLUGGED
PIN 9 - PLUGGED
PIN 10 -PLUGGED
PIN 11 -PLUGGED
PIN 12 -PLUGGED
