Skyjack SJ85 AJ Service Manual

A B C D E F G H
V
Z
Y
X
W
67
SJ85 AJ
229044ADA
3.13 Jib and Platform Rotate Harness Connections
M198228AB_M168650AB
WHITE (02)
WHITE (02)
RED PURPLE (36)
WHITE RED BLACK (37)
ORANGE BLACK(34)
ORANGE WHITE (35)
02
02
02
02
08A
08
04
04
04
118
82
45
43
34
35
36
37
59
60
A
CAVITY WIRE NO. COLOUR DESCRIPTION
1
34 ORANGE/BLK JIB DOWN
2 02
WHITE (SPLICE 2)
GROUND
CAVITY WIRE NO. COLOUR DESCRIPTION
1
35 ORANGE/WHITE
JIB UP
2 02
WHITE (SPLICE 2)
GROUND
CAVITY WIRE NO. COLOUR DESCRIPTION
1
37 WHITE/RED/BLK ROTATE CCW
2 02
WHITE (SPLICE 1)
GROUND
CAVITY WIRE NO. COLOUR DESCRIPTION
1
36 RED/PURPLE ROTATE CW
2 02
WHITE (SPLICE 1)
GROUND
DETAIL A
SCALE 1 : 2
