Skyjack SJ85 AJ Service Manual

34
SJ85 AJ229044ADA
2.3 Torque Specifications for Fasteners (Metric)Table
Size
Torque
Type
SAE2 SAE 5 SAE 8
Dry Lubed Dry Lubed Dry Lubed
M5 x 0.80
(in-lb) (54) (41) (78) (59) (12) (9)
Nm 6.1 4.6 8.8 6.7 1.4 1.0
M6 x 1.00
(in-lb) (92) (69) (133) (99) (13) (10)
Nm 10.4 7.8 15 11.2 1.5 1.1
M7 x 1.00
(in-lb) (156) (116) (222) (167) (23) (17)
Nm 17.6 13.1 25.1 18.9 2.6 1.9
M8 x 1.25
(in-lb) (225) (169) (333) (242) (25) (19)
Nm 25.4 19.1 37.6 27.3 2.8 2.1
M10 x 1.50
ft-lb 37 28 53 40 (41) (31)
Nm 50 38 72 54 4.6 3.5
M12 x 1.75
ft-lb 65 49 93 69 (43) (32)
Nm 88 66 126 94 4.9 3.6
M14 x 2.00
ft-lb 104 78 148 111 (60) (45)
Nm 141 106 201 150 6.8 5.1
M16 x 2.00
ft-lb 161 121 230 172 (68) (51)
Nm 218 164 312 233 7.7 5.8
M18 x 2.50
ft-lb 222 167 318 238 12 9
Nm 301 226 431 323 16 12
M20 x 2.50
ft-lb 314 235 449 337 14 10
Nm 426 319 609 457 19 14
M22 x 2.50
ft-lb 428 321 613 460 25 18
Nm 580 435 831 624 34 24
M24 x 3.00
ft-lb 543 407 776 582 25 20
Nm 736 552 1052 789 34 27
M27 x 3.00
ft-lb 796 597 1139 854 45 35
Nm 1079 809 1544 1158 61 47
M30 x 3.50
ft-lb 1079 809 1543 1158 50 35
Nm 1463 1097 2092 1570 68 47
M33 x 3.50
ft-lb 1468 1101 2101 1576 70 55
Nm 1990 1493 2849 2137 95 75
M36 x 4.00
ft-lb 1886 1415 2699 2024 80 60
Nm 2557 1918 3659 2744 108 81
NOTE: Lubed includes lubricants such as lubrizing, oil, grease, or uncured Loctite. 1375AA
